SWAGE SLEEVE & RECEIVER SYSTEM-SWAGE SLEEVE & RECEIVER SYSTEM (3)

ITEM

A

D

L

T

TO USE WITH

7813S-06-DOME

0.70"

0.38"

2-3/16”

1/4"

78137S-0603

7813S-08-DOME

0.70"

0.48"

2-3/16”

5/16"

78137S-0805

7813S-10-DOME

0.70"

0.48"

2-3/16”

3/8"

78137S-1006

ITEM

A

B

L

AFTER SWAGE

TO USE WITH

78137S-0603

1/8"

1/4"-20

0.89"

0.185"

7813S-06-DOME

78137S-0805

3/16"

5/16"-18

0.96"

0.245"

7813S-08-DOME

78137S-1006

1/4"

3/8"-16

1.25"

0.368"

7813S-10-DOME

ITEM

SIZE

A

B

TO USE WITH

30731S-10

5/8”

3/8”

11/16”

7813S-06-DOME

30731S-13

5/8”

1/2”

11/16”

7813S-08-DOME / 7813S-10-DOME
